Ergonomic, safe and fast
The T16 L is versatile. Like other electric pallet trucks, it is optimized for transporting goods over short distances and for loading and unloading lorries. Thanks to its lifting function, however, it is also ideally suited for order picking in logistics and restocking shelves in retail. With its powerful motor, the T16 L pallet truck reaches speeds of up to 6 km/h, both loaded and unloaded, and easily handles gradients. The rounded chassis, the low skirt and the long, low-mounted tiller provide maximum protection. With a lift height of up to 675 mm, the T16 L enables back- and knee-friendly work. The optional Autolift function automatically adjusts the lift height in proportion to the increasing height of the load. The intuitively designed tiller head includes all control functions and ensures easy handling. The robust chassis protects the truck from damage in tough continuous operation.
Characteristics
Safety
The long tiller with deep mounting point provides a large safety distance between the operator and the truck. A deep skirt covers the wheels, effectively protecting the operator’s feet from injury. The emergency stop button is easily accessible and increases safety in case of emergency. The tiller head of the T16 L is designed to enclose the operator’s hands and protect them. When cornering, the truck immediately adjusts its speed to the steering angle, protecting the operator from risky manoeuvres.
- Long, low mounted tiller
- Deep skirt as foot guard
- Easily accessible emergency stop button
- Tiller with hand protection
- Speed adjustment in curves
Ergonomics
The T16 L offers a lifting height of up to 675 mm, which means that the operator does not have to bend their knees or back when loading. The ergonomically designed tiller head contains all operating functions and can be steered with one hand, even when wearing gloves. Travel speed and steering resistance automatically and continuously adjust to the steering angle. Additional switches can be fitted as an option, allowing easy control of the lift height on both sides of the truck. As a further option, the T16 L can be equipped with an Autolift function that automatically adjusts the fork height to the load on the forks. This eliminates the need for manual operation of the lift and the operator is able to pick orders at the optimum height without unnecessary interruption. There are also holders available for important work equipment such as scanners, clipboards or shrink wrap.
- Working height that is easy on the back and knees
- Ergonomically designed tiller head
- Automatic speed adjustment
- Lift button provides simple control of the lift height, available as option
- Optional Autolift function for lift adjustment
Handling
With or without a load, the T16 L reaches speeds of up to 6 km/h. Even when fully loaded, it can handle the most challenging gradients, making it ideal for a wide range of operating conditions. It lifts up to 800 kg to maximum height while providing a high level of operator safety. Its long, low-mounted tiller and electric power steering ensure optimal manoeuvrability in tight spaces. The castor wheels automatically adjust to the load, operating situation and speed, ensuring high operating stability and good traction on uneven ground. With the optional creep speed function (available as option) and Linde Proportional Speed, the T16 L can be safely manoeuvred even in the tightest spaces.
- Speed up to 6 km/h
- High gradeability
- Load capacity up to 800 kg at maximum height
- Manoeuvrability in tight spaces
- Creep speed function (optional) and proportional speed control
Servicing
Thanks to its robust design, the T16 L features low maintenance costs and ensures a long service life even under intensive operating conditions. The CAN bus structure enables fast service processes and rapid truck diagnostics, which significantly reduces downtime. For fast maintenance, the essential components of the T16 L are easily accessible. All covers are optimally protected from damage by the contours of the chassis. The tiller arm is reinforced with a steel insert, which provides additional robustness and minimizes maintenance requirements.
- Robust construction for low maintenance costs
- CAN bus structure for fast diagnostics
- Easy access to the technical compartment
- Covers optimally protected by chassis contours
- Steel reinforced tiller arm
Technical Data
| Model | Load capacity/Load | Lift | Travel speed, with/without load | Turning radius | Battery voltage/rated capacity (5h) |
|---|---|---|---|---|---|
| T16L | 1.6 (t) | 550 (mm) | 6 / 6 km/h | 1512 / 1575 (mm) | 24 / 62 (125) (V)/(Ah) o. kWh |
Optional Equipment
-
Lateral battery change
-
Integrated charger
-
Li-ION technology
-
Cold store variant
-
Load backrest
-
Autolift
-
Creep speed function
Lateral battery change
Lateral battery removal with roller bearings allows for quick changes, making it more efficient especially for use in multi-shift operation.
Integrated charger
The integrated charger increases flexibility: The pallet truck can be charged nearly everywhere and at any time.
Li-ION technology
In addition to the classic lead-acid batteries, the trucks can be equipped with a new generation of Li-ION batteries.
Cold store variant
The cold store variant guarantees full availability and performance of the truck down to minus 35 degrees.
Load backrest
The load backrest ensures that loads cannot slip backwards and fall on the operator when the load carrier is raised.
Autolift
Sensors on the truck automatically adjust the order picking lift during loading. The load height for the operator thus remains the same even when goods are stacked on the pallet.
Creep speed function
The creep speed function slows down the truck and makes difficult manoeuvres in narrow aisles easier and safer.
