Pallet trucks T14–T20

Compact transport helper

Maximum manoeuvrability in the tightest of spaces

The T14–T20 pallet trucks can be manoeuvred easily and quickly, even in the tightest spaces, thanks to their particularly compact design. Thanks to their robust chassis and reinforced forks, the trucks can transport loads of up to two metric tons – depending on the model. The central and low-set tiller improves the manoeuvrability of the truck whilst an optionally available proportional speed control reduces travel speed automatically in relation to the tiller angle. The electric pallet trucks can also be equipped with Li-ION batteries as an option. These particularly compact Li-ION batteries are also available for the T14 and T16 models, making them ideal helpers in retail and when delivering goods by truck in cities. The ergonomic controls mounted on the tiller head enable comfortable and safe operation, even in the most confined spaces. Numerous optional extras, such as triple load wheels for exceptionally quiet operation, a load backrest, storage space and an A4 clipboard, enable tailor-made truck configurations for every application.

Characteristics

Safety

The design of the T14–T20 pallet trucks improve operator safety; the low chassis protects feet, while the long, low-set tiller ensures that the operator always keeps sufficient distance from the pallet truck during operation. In addition, a bar above the controls protects the hands. If the operator releases the butterfly control or changes the direction of travel, the truck brakes automatically and an automatic parking brake prevents unintentional rolling away on gradients. If the tiller is in danger of trapping the operator whilst manoeuvring, a belly switch on the tiller head stops the truck.

  • Deep set chassis as foot guard
  • Low mounted tiller with hand guard
  • Automatic parking brake
  • Belly switch on tiller head

Ergonomics

The pallet trucks of the T14–T20 series are designed for comfort and user-friendliness. All controls on the ergonomic tiller head can be operated easily with either hand and allow handling that is as precise as it is comfortable. To keep noise levels as low as possible for the operator, the pallet trucks are optimised for low-noise operation. A multifunction display with operating hours counter, maintenance schedule, error code and battery level display provide an overview of all important information at all times without distracting the operator. Depending on the battery size, the cover offers storage areas for work utensils such as a clipboard, shrink wrap or goods scanner as standard.

  • Easy to handle tiller
  • Quiet operation
  • Multifunction display
  • Many storage areas

Handling

The powerful electric motor provides precise and strong power delivery in every working situation. As an optional feature, the proportional speed control reduces the travel speed automatically in relation to the tiller angle. This allows the truck to be operated safely and slowly in tight spaces with a vertical tiller. A booster effect automatically increases engine power on uneven and steep terrain, whilst the low chassis and rounded battery cover also ensure good visibility of the forks. Users have a wide choice of fork lengths and additional load wheels. The Li-ION battery version allows for interim charging, meaning trucks can be charged during breaks and downtime.

  • Powerful electric motor
  • Proportional speed option
  • Booster function
  • Li-ION battery as option

Service

The robust AC motor enables long maintenance intervals. In addition, automatically adjustable castor wheels as well as low-wear, maintenance-free components, and the robust covering ensure a long service life, high availability and low service costs. For fast, uncomplicated maintenance, service technicians have access to all relevant components via the front service panel. A central interface links all the truck’s electronic components via the CAN bus system. This means that all truck data can be read out on site via a laptop. Remote fault diagnostics and software updates are also possible when equipped with an optional data transmission unit.

  • Low maintenance AC motor
  • Robust truck construction
  • Easily accessible service components
  • CAN bus system
  • Optionally available data transmission unit

Videos & Images

T14 - T20 pallet truck from Linde Material Handling

Technical Data

Model Load capacity/Load Lift Travel speed, with/without load Turning radius Battery voltage/rated capacity (5h)
T14 1.4 (t) 125 (mm) 6 / 6 km/h 1365 / 1437 (mm) 24 / 62 (125) (V)/(Ah) o. kWh
T16 1.6 (t) 125 (mm) 6 / 6 km/h 1438 / 1510 (mm) 24 / 150 (V)/(Ah) o. kWh
T18 1.8 (t) 125 (mm) 6 / 6 km/h 1438 / 1510 (mm) 24 / 150 (V)/(Ah) o. kWh
T20 2.0 (t) 125 (mm) 6 / 6 km/h 1510 / 1582 (mm) 24 / 250 (V)/(Ah) o. kWh

Optional Equipment

Single, tandem or triple load wheels

The load wheels can be selected to suit the application. The more wheels, the quieter the truck.

Alternative forks

The length and width of the forks can be configured according to the application. A marking for easy handling of pallets in transverse direction is available on request.

Integrated charger

An integrated charger is available for both Li-ION and lead-acid batteries.

Active Foot Bumper

An active foot bumper that registers even light foot contact with the truck, stops the truck, and protects the driver, even in confined spaces.

Load backrest

The load backrest offers the operator additional protection by preventing high loads from sliding back.

Battery covers

Battery covers are available in either plastic or steel and provide additional storage space, e.g., for clipboards and scanners.
