  • 0 - 2,000 (kg)
  • 0 - 2,424 (mm)

Pallet stackers D12 HP SP

Double deck power pack

Top performance for maximum goods handling

The D12 HP SP electric double-deck pallet stackers are high-performance vehicles that can simultaneously pick up and transport two pallets. They are suitable for efficient loading and unloading of multi-level delivery vehicles, storage and retrieval, fast transport journeys and for occasional picking tasks. As a high-performance version, the D12 HP SP offer high travel and lifting speeds for maximum handling performance. The Linde OptiLift assistance system ensures precise load handling and therefore also increases productivity. A 5-point configuration with castor wheels guarantees maximum stability at all times. As protection in the event of collisions, the operators are surrounded by a solid steel apron. Together with the innovative Linde e-driver control concept, the unique 45° degree standing position ensures an ergonomic body posture and ideal all-round visibility. For greater manoeuvrability in tight spaces, a shortened truck version with Li-ION battery is available as an option.

Characteristics

Safety

The D12 HP SP’s fixed stand-on platform is surrounded to the rear by a robust, waist-high steel apron that protects the operator from harm in the event of a collision. Thanks to the special design of the stand-on platform, the operator’s body remains within the vehicle contours at all times, which prevents injuries. Additional protection is provided by foot detection. It registers when the operator’s feet leave the platform and automatically brings the vehicle to a stop. The wide mast provides excellent visibility of the load, which significantly improves safety during goods handling. Load integrity is ensured by a soft-landing function that helps the forks touch down gently on the ground. Thanks to Linde’s integrated Curve Assist, the vehicle automatically adjusts its cornering speed to prevent accidents. If the operator releases the butterfly control, the truck stops automatically.

  • Sturdy steel apron as a protective shield
  • Feet detection for operator protection
  • Adjusted vehicle speed in curves
  • Optimum visibility through the mast
  • Soft landing function to protect the load

Ergonomics

Precise lifting movements are the key to ergonomic load handling. That’s why the D12 HP SP is equipped with the Linde OptiLift. The operator platform and control handle unit is completely decoupled from the chassis and fully suspended. This absorbs vibrations and shocks and guarantees comfortable, stress-free working. At the same time, the height-adjustable steering can be adapted to the physical requirements of the operator. Manoeuvring is possible without much effort thanks to the electric power steering. Travel speed and steering resistance are automatically and continuously adjusted to the steering angle. In the D12 HP SP, the operator stands at a 45° angle to the fork direction. This gives them a good view of their surroundings in any direction of travel without straining their back and neck with excessive turning movements. On request, the vehicles can be equipped with the innovative Linde e-driver control system. It is optimised for the 45° standing position, contains all important control functions and can be operated with one hand. A multi-function display provides the operator with all important information.

  • Linde OptiLift assistance system
  • Fully decoupled and suspended operator platform
  • Electric power steering
  • Unique control concept Linde e-driver with 45° operating position
  • Multifunction display

Handling

The high-performance D12 HP SP models reach a top speed of 14 km/h without load. When travelling with two pallets, the powerful 3 kW three-phase AC motor enables up to 7.5 km/h. A powerful lift motor provides more speed when lifting and lowering the load, which noticeably improves performance when handling pallets. For more performance with double-deck loading, the D12 HP SP can be equipped with Linde Speed Management. A start-up assistant prevents unintentional rolling backwards on sloping ground. Consistent traction and stability, especially when traversing ramps or uneven ground, are provided by a 5-point configuration with optional electrically controlled and hydraulically operated castor wheels on both sides, as well as a centre-mounted drive wheel. The D12 HP SP can be equipped with a new generation of Li-ION batteries, for which a corresponding on-board charger is also available. In addition, the trucks are available with a shorter battery compartment in combination with a 6 kWh Li-ION battery. The shorter wheelbase reduces the turning radius and makes the truck ideal for use in tight spaces.

  • High travel and lifting speeds
  • Powerful 3 kW three-phase motor
  • Linde Speed Management for double-deck loading
  • 5-point configuration for increased stability
  • Shorter battery compartment for smaller turning radius

Service

The electric motor of the D12 HP SP is maintenance-free thanks to modern three-phase AC technology, which ensures high availability and minimises service costs. The robust cladding parts and a stable chassis ensure reliability even under tough operating conditions. The vehicle was developed on the premise of ‘design to service’. This means that service technicians have quick access to all relevant components. With CAN bus all vehicle data can be accessed through a diagnostic connector. The trucks’ modern electric-electronic architecture allows software updates and new functions to be remotely installed at any time when the truck is equipped with the optional data transfer unit.

  • Maintenance free engine
  • Robust construction
  • Diagnosis via CAN bus
  • Easily accessible components
  • Modern E/E architecture

Videos & Images

D12 HP SP

Technical Data

Model Load capacity/Load Lift Travel speed, with/without load Turning radius Battery voltage/rated capacity (5h)
D12 HP SP 1.2 / 1.0/1.0 / 2.0 (t) 2424 (mm) 11 / 14 km/h 2221 / 2291 (mm) 24 / 375 (V)/(Ah) o. kWh

Optional Equipment

Li-ION-technology

In addition to the classic lead-acid batteries, the new generation of Li-ION batteries is also available.

Steering

The vehicles can be equipped either with a standard double handlebar or with the Linde e-driver steering concept, whose handlebar is optimised for the 45° position and can be operated with one hand.

Speed Zoning

With the software-based speed management connect:zi, different safety zones can be set up with automatic speed adjustment.

Cold store design

The cold store version guarantees full availability and performance of the truck up to minus 35° Celsius.

Foot detection

A foot sensor registers when the operator’s feet leave the standing platform. Accordingly, the speed is reduced until the vehicle comes to a complete halt.

Linde BlueSpot™

The Linde BlueSpot™ increases safety during operation, as the LED spotlight makes vehicles visible if they cannot be heard.

Speed Management

In double-deck operation, Linde Speed Management adjusts the vehicle speed depending on the load weight and lifting height, thereby guaranteeing maximum performance and safety.
